[5% off $611.00 ] PRODUCTIVITYMOTION 2-AXIS MOTION CONTROL
$580.45USD
Precio no incluye IVA
DESCUENTO EXCLUSIVO TIENDA EN LINEA
PRODUCTIVITYMOTION 2-AXIS MOTION CONTROLLER, 1 MHZ MAXIMUM SWITCHING FREQUENCY, 12 HIGH-SPEED INPUT POINT(S), SINKING, 2-CHANNEL, DIFFERENTIAL ENCODER INPUT(S), 6 HIGH-SPEED OUTPUT POINT(S), SINKING/SOURCING, 2-CHANNEL, DIFFERENTIAL OUTPUT(S).
Modelo: PS-AMC2
Documentos:
Jueves, 05 de Diciembre de 2024
*Sujeto a cambio sin previo aviso de acuerdo a disponibilidad con fabricante.
Lunes, 09 De Diciembre De 2024
*Sujeto a cambio sin previo aviso de acuerdo a disponibilidad con fabricante.
Precio (no incluye IVA):
$580.45USD
Atributos del producto
| Brand | ProductivityMotion |
|---|---|
| Item | 2-axis motion controller |
| Maximum Switching Frequency | 1 MHz |
| Number of High-Speed Capable Input Points | 12 |
| Nominal Input Voltage | 5-24 VDC |
| Discrete Input Type | Sinking |
| Number of Non-Isolated Input Commons | 2 |
|---|---|
| Number Of Input Channels | 2 |
| Encoder Input Type |
|
| Number of High-Speed Capable Output Points | 6 |
| Nominal Output Voltage | 5-24 VDC |
| Discrete Output Type | Sinking/sourcing |
| Number of Non-Isolated Output Commons | 2 |
| Load Current | 50 mA/point |
| Number Of Output Channels | 2 |
| Pulse Output Channel Type |
|
| Position Scaling |
|
| Frequency Measurement |
|
| Output Pulse Mode(s) |
|
| Axis Profile(s) |
|
| External Power Requirement | 24 VDC |
| For Use With | Productivity series CPUs with (2) Ethernet 10/100Base-T (RJ45) ports |
| Programming Software | Productivity Suite programming software v3.10 or later |
| Additional Information | P2000/P3000 CPUs can support up to (4) motion controllers, P1000 CPUs can support up to (1) motion controller |
