MARATHON XRI SERIES PREMIUM EFFICIENCY A
$628.00USD
Precio no incluye IVAMARATHON XRI SERIES PREMIUM EFFICIENCY A
Modelo: D393A
ENVIO GRATIS en compras
mayores
a $650.00 USD.
1 AÑO de Garantía SDI
Fecha Entrega:
Sin disponibilidad por el momento.
Unidades Disponibles: 0
Precio (no incluye IVA):
$628.00USD
Atributos del producto
| Brand | Marathon |
|---|---|
| Item | Motor |
| Series | XRI |
| Efficiency Group | Premium efficiency |
| Efficiency | 78.5 |
| Voltage Type | AC |
Ver más
| Motor Type | Induction |
|---|---|
| Motor Application | General purpose, inverter rated and 4-in-1 |
| Horsepower Rating | 1hp |
| Number of Phases | 3 |
| Voltage Rating | 230/460 VAC, suitable for 208 VAC at 60 Hz |
| Synchronous Speed | 3600rpm |
| Nameplate RPM | 3450rpm |
| Overload Type | None |
| Enclosure Type | TEFC |
| Shaft Type | Round with square key |
| Shaft Diameter | 5/8in |
| Shaft Material | 1144 Stressproof (C-223) steel |
| Motor Frame | 56C |
| Frame Material | Rolled steel |
| Electrically Reversible | Yes |
| Insulation Class | Class F |
| IP Rating | IP43 |
| Constant Torque Rating | 10 |
| Variable Torque Rating | 10 |
| Service Factor | 1.15 |
| NEMA Design | Design B |
| Junction Box Orientation | F1 |
| Mounting | Removable base/C-face |
| Mounting Orientation | Horizontal or vertical |
