[3% off $2873.00 ] WEG ELECTRIC SSW07 SERIES FULL-FEATURED
$2786.81USD
Precio no incluye IVA
DESCUENTO EXCLUSIVO TIENDA EN LINEA
WEG ELECTRIC SSW07 SERIES FULL-FEATURED SOFT STARTER, 171A, 220/460/575 VAC AT 3-PHASE, TRIP CLASS 5/10/20/30, RATED FOR 3 START/HOUR, INTERNALLY BYPASSED. OPTIONAL MODBUS RTU CARDS AVAILABLE.
Documentos:
Este producto incluye
Envío gratis
* Aplican restricciones
Fecha Entrega:
Precio (no incluye IVA):
$2786.81USD
Atributos del producto
| Brand | WEG Electric |
|---|---|
| Item | Soft starter |
| Controller Type | Full-featured |
| Series | SSW07 |
| Amperage Rating | 171A |
| Nominal Input Voltage | 220/460/575 VAC at 3-phase |
| Nominal Output Voltage | 220/460/575 VAC at 3-phase |
|---|---|
| Trip Class | Trip Class 5/10/20/30 |
| Starts per Hour | 3 |
| Internally Bypassed | Yes |
| Number of Input Phases | 3 |
| Number of Output Phases | 3 |
| Number of Controlled Output Phases | 3 |
| Control Mode | Sinusoidal |
| Control Power Requirement | 110-240 VAC |
| Derating | Unit may require derating for applications other than fans and pumps; see specifications for appropriate derating |
| Temperature Rating | 0 to 55 deg C |
| Enclosure Type | Enclosed |
| Mounting | 35mm DIN rail, panel or wall |
| Frame Size | 3 |
| IP Rating | IP00 |
| Output Frequency Range | 50-60 Hz |
| Output Type | SCR output |
| Reverse Capability | None |
| Additional Information | Optional Modbus RTU cards available |
