IRONHORSE MTDP SERIES PREMIUM EFFICIENCY
$408.00USD
Precio no incluye IVAIRONHORSE MTDP SERIES PREMIUM EFFICIENCY AC INDUCTION MOTOR, INVERTER RATED, 1HP, 3-PHASE, 208-230/460 VAC, 1800RPM, ODP, 143T FRAME, ROLLED STEEL, RIGID BASE ONLY MOUNT.
Modelo: MTDP-001-3BD18
Fecha Entrega:
Viernes, 11 de Septiembre de 2026
Unidades Por Llegar: 8
Precio (no incluye IVA):
$408.00USD
Atributos del producto
| Brand | IronHorse |
|---|---|
| Item | Motor |
| Efficiency Group | Premium efficiency |
| Efficiency | 85.5 |
| Voltage Type | AC |
| Motor Type | Induction |
| Motor Application | Inverter rated |
|---|---|
| Horsepower Rating | 1hp |
| Number of Phases | 3 |
| Voltage Rating | 208-230/460 VAC |
| Synchronous Speed | 1800rpm |
| Nameplate RPM | 1745rpm |
| Overload Type | None |
| Enclosure Type | ODP |
| Shaft Type | Round with square key |
| Shaft Diameter | 7/8in |
| Shaft Material | 1045 hot rolled (C-204) steel |
| Motor Frame | 143T |
| Frame Material | Rolled steel |
| Electrically Reversible | Yes |
| Insulation Class | Class F |
| IP Rating | IP23 |
| Constant Torque Rating | 10 |
| Variable Torque Rating | 20 |
| Service Factor | 1.15 (sine), 1.0 (drive) |
| NEMA Design | Design B |
| Junction Box Orientation | F1 |
| Mounting | Rigid base only |
| Mounting Orientation | Horizontal |
| Additional Information | Pre-drilled for optional MTADP-CDR-140 current diverter ring (sold separately) |
