MARATHON PREMIUM EFFICIENCY AC INDUCTION
$642.00USD
Precio no incluye IVAMARATHON PREMIUM EFFICIENCY AC INDUCTION MOTOR, JET PUMP AND INVERTER RATED, 1HP, 3-PHASE, 230/460 VAC, SUITABLE FOR 208 VAC AT 60 HZ, 3600RPM, TEFC, 56J FRAME, ROLLED STEEL, RIGID BASE/C-FACE MOUNT.
Modelo: J063A
ENVIO GRATIS en compras
mayores
a $650.00 USD.
1 AÑO de Garantía SDI
Fecha Entrega:
Lunes, 15 de Junio de 2026
Unidades Disponibles: 4
Precio (no incluye IVA):
$642.00USD
Cantidad:
Atributos del producto
| Brand | Marathon |
|---|---|
| Item | Motor |
| Efficiency Group | Premium efficiency |
| Efficiency | 78.5 |
| Voltage Type | AC |
| Motor Type | Induction |
Ver más
| Motor Application | Jet pump and inverter rated |
|---|---|
| Horsepower Rating | 1hp |
| Number of Phases | 3 |
| Voltage Rating | 230/460 VAC, suitable for 208 VAC at 60 Hz |
| Synchronous Speed | 3600rpm |
| Nameplate RPM | 3450rpm |
| Overload Type | None |
| Enclosure Type | TEFC |
| Shaft Type | Round threaded 20 UNF-2A |
| Shaft Diameter | 5/8in |
| Shaft Material | 416 stainless (C-503) steel |
| Motor Frame | 56J |
| Frame Material | Rolled steel |
| Electrically Reversible | Yes |
| Insulation Class | Class B |
| IP Rating | IP43 |
| Service Factor | 1.15 |
| NEMA Design | Design B |
| Junction Box Orientation | F1 |
| Mounting | Rigid base/C-face |
| Mounting Orientation | Horizontal |
