[3% off $471.00 ] 2-PORT MODBUS GATEWAY
$456.87USD
Precio no incluye IVA
DESCUENTO EXCLUSIVO TIENDA EN LINEA
• SUPPORTS SURGE PROTECTION FOR D.C. POWER PORTS WITH LINE TO LINE 2 KV, AND LINE TO EARTH 4 KV; FOR SIGNAL PORTS WITH 4 KV.
• PROVIDES 2 X 10/100 MBPS ETHERNET PORTS FOR LAN REDUNDANCY
• INTEGRATION OF MODBUS TCP AND MODBUS RTU/ASCII NETWORKS
• SUPPORTS UP TO 921.6 KBPS, AND ANY BAUD RATE SETTING
• SUPPORT UP TO 16 CONNECTIONS ON EACH SERIAL PORT UNDER MODBUS MASTER MODE AND 32 SESSIONS UNDER MODBUS SLAVE MODE.
• SOFTWARE SELECTABLE RS-232/422/485 COMMUNICATION
• MOUNTS ON DIN-RAIL AND WALL MOUNT
• BUILT-IN 15 KV ESD PROTECTION FOR ALL SERIAL SIGNALS
• AUTOMATIC RS-485 DATA FLOW CONTROL
Fecha Entrega:
Precio (no incluye IVA):
$456.87USD
Atributos del producto
| Brand | Advantech |
|---|---|
| Item | Modbus gateway |
| Ethernet Devices Modbus Role | Modbus TCP Client/Server |
| Serial Devices Modbus Role | Master/Slave |
| Number of Ports | 4 |
| Communication Port and Connection Type(s) | <ul class="techattribute"><li>(2) Ethernet 10/100Base-T (RJ45)</li><li>(2) RS-232/422/485 (9-pin D-sub male)</li></ul> |
| Port Protocol(s) |
|
|---|---|
| Port Speed(s) |
|
| Modes | Direct access, agent |
| Number of Simultaneous Ethernet Connections | 64 |
| Number of Serial Devices | 64 |
| Interface | Browser (secure) |
| Housing Material | Metal |
| IP Rating | IP30 |
| Mounting | 35mm DIN rail |
| Application | Hazardous location rated |
| External Power Requirement | 12-48 VDC |
| Additional Information | Ethernet ports can also serve as LAN redundancy |
