CFW320-IOAENC

[3% off $108.00 ] WEG ELECTRIC CFW320 SERIES COMMUNICATION

$104.76USD

Precio no incluye IVA

DESCUENTO EXCLUSIVO TIENDA EN LINEA
WEG ELECTRIC CFW320 SERIES COMMUNICATION MODULE, MODBUS RTU, 1 PORT, (1) MINIB-USB PORT(S). FOR USE WITH WEG CFW320 SERIES AC DRIVES. (1) 6.5FT/2M USB A TO MINIB-USB CABLE INCLUDED.

Modelo: CFW320-IOAENC

Documentos:

CFW320-IOAENC 2D Drawing

Product Line Brochure

Drive User Manual

Drive User Manual Addendum

Product Cut Sheet

Combo Module Quick Start Guide

CFW320-IOAENC STP 3D Model

Technical Specifications

ENVIO GRATIS en compras mayores a $650.00 USD.

1 AÑO de Garantía SDI

Fecha Entrega:

Debug Url: "https://proyectos.sdindustrial.com.mx/apps/tienda/StockAutomation/fechaentrega.php?vcModelo=CFW320-IOAENC"

Debug Cantidad: "24"

Debug Mensaje: "* En BackOrder"

Debug FechaEmbarque: "Lunes, 05 de Enero de 2026"

Debug Fabricante: "AutomationDirect"

Debug idFabricante: "478"

Debug idProveedor: "106"

* En BackOrder

Lunes, 05 de Enero de 2026

											*** Condición ejecutada: Entró en * En BackOrder + AutomationDirect ***
											*** ocultaCompra:  ***

Precio (no incluye IVA):

$104.76USD

Cantidad:

Atributos Arriba

Atributos del producto

Brand	WEG Electric
Item	Combo module
I/O Module Type	Encoder analog
Series	CFW320
Maximum Switching Frequency	400 kHz
Input High Speed Type	1-channel quadrature encoder

Number of Analog Input Channels	1
Analog Input Signal Type	Current/voltage
Number of Isolated Analog Input Commons	1
Input Resolution	10-bit
Input Current Signal Range	0-20 mA, 4-20 mA
Input Voltage Signal Range	0-10 VDC
Number of Analog Output Channels	2
Analog Output Signal Type	Current/voltage
Number of Isolated Analog Output Commons	1
Output Resolution	12-bit
Output Current Signal Range	0-20 mA and 4-20 mA
Output Voltage Signal Range	0-10 VDC
For Use With	WEG CFW320 series AC drives
Additional Information	Not for use in full vector control applications
